High Precision Anti-interference 760 ZNC EDM Die Sinking Machine

The High Precision Anti-Interference 760 ZNC EDM Die Sinking Machine is an advanced tool designed for precision machining in a variety of industrial applications. This state-of-the-art machine features high precision control with an anti-interference system, ensuring reliable and accurate performance even in demanding environments.

Equipped with a robust ZNC (Z-axis Numerical Control) system, the 750 ZNC EDM machine offers unparalleled control and stability, allowing for intricate and detailed die sinking operations. Its high precision machining capabilities are ideal for manufacturing complex parts and molds with exacting tolerances.

The machine’s anti-interference technology ensures smooth operation, reducing the risk of errors caused by external electronic disturbances. This feature is particularly valuable in environments with high electromagnetic interference, ensuring consistent and reliable output.

Built with a durable and rigid structure, the 750 ZNC EDM machine provides long-lasting performance and can handle heavy-duty tasks with ease. Its user-friendly interface and advanced software allow operators to easily program and monitor machining processes, enhancing productivity and efficiency.

Whether used in automotive, aerospace, or electronics industries, the High Precision Anti-Interference 750 ZNC EDM Die Sinking Machine is an essential tool for any operation requiring high precision and reliability. Its combination of advanced features and robust construction makes it a standout choice for professionals seeking top-tier performance in EDM machining.

CONTACT US Jiangsu Chuangwei CNC Machine Tool Co., Ltd.

Mechanical parameters

Model 760-ZNC
Workbench 1000*600 mm
Left and right stroke 700 mm
Maximum front and rear stroke 600mm
Spindle stroke 300 mm
Head stroke 300 mm(auto)
Oil tank size 1900*1080*620mm
Three-axis positioning accuracy 5us
Reset positioning accuracy 3us
Minimum resolution 5us
Maximum distance between spindle and workbench 960 mm
Maximum electrode capacity 300 kg
Machine weight 4200 kg(net)
Packing size 2400*2000*2500 mm
Filter box weight 800 Litre

Control system parameters

Specifications ZNC power box specifications
Control method, number of axes Numerical control closed loop, single axis (Z axis)
Minimum X.Y.Z setting size 0.005mm
Maximum X.Y.Z setting size 9999.995mm (9999.9999mm)
Coordinate system Incremental value (INC), absolute (ABS)
Screen display 15" CRT, color LCD
Control system Industrial grade computer
(Remote control) shift rate 0.005mm (per unit) X1, X5, X10
Program file storage 60 groups
Maximum processing current A 50 60 100
Input power KVA 4.5 6 10
Maximum processing speed mm/min 360 560 700
Electrode consumption % <0.2
Optimal surface finish mRa 0.18
Appearance dimensions mm 860*720*1950
Packaging dimensions mm 900*1000*2090
Net weight kgs 210
Number of processing setting groups 1
Number of processing setting segments 10
Processing method Upward processing, downward processing
Shaking method None
Maximum number of holes for continuous processing 1
