Energy saving Waterproof Dustproof 650 ZNC EDM Die Sinking Machine

The Energy Saving Waterproof Dustproof 650 ZNC EDM Die Sinking Machine is a cutting-edge tool designed for precision and efficiency in electrical discharge machining. This advanced machine features a robust build that ensures durability and reliability in demanding industrial environments. Its waterproof and dustproof capabilities guarantee long-term operation without the risk of contamination or damage from environmental factors.

One of the standout features of the 650 ZNC EDM Die Sinking Machine is its energy-saving technology, which significantly reduces power consumption while maintaining high-performance levels. This makes it an environmentally friendly option that also helps in reducing operational costs. The machine is equipped with a user-friendly interface that allows for easy programming and operation, ensuring that even complex tasks can be handled with ease.

The 650 ZNC model boasts accuracy and precision, essential for detailed die sinking tasks. It includes advanced control systems that provide stable and consistent performance, minimizing errors and enhancing productivity. With a focus on safety and efficiency, this machine incorporates state-of-the-art components that comply with the highest industry standards.

The Energy Saving Waterproof Dustproof 650 ZNC EDM Die Sinking Machine is an exceptional choice for industries looking to improve their machining processes with a reliable, efficient, and eco-friendly solution.

CONTACT US Jiangsu Chuangwei CNC Machine Tool Co., Ltd.

Mechanical parameters

Model 650
Workbench 900*500 mm
Left and right stroke 600 mm
Forward and backward stroke 500 mm
Spindle stroke 250 mm
Head stroke 250 mm(auto)
Oil tank size 1570*920*570mm
Three-axis positioning accuracy 5us
Reset positioning accuracy 3us
Minimum resolution 5us
Maximum distance between spindle and workbench 800 mm
Maximum electrode capacity 120 kg
Machine weight 2200 kg(net)
Packing size 2150*1800*2400 mm
Filter box weight 800 Litre

Control system parameters

Specifications ZNC power box specifications
Control method, number of axes Numerical control closed loop, single axis (Z axis)
Minimum X.Y.Z setting size 0.005mm (0.001mm)
Maximum X.Y.Z setting size 9999.995mm (9999.9999mm)
Coordinate system Incremental value (INC), absolute (ABS)
Screen display 15" CRT, color LCD
Control system Industrial computer
(Remote control) shift rate 0.005mm (per unit) X1, X5, X10
Program file storage 60 groups
Maximum processing current A 50 60 100
Input power KVA 4.5 6 10
Maximum processing speed mm/min 360 560 700
Electrode consumption % <0.2
Optimal surface finish mRa 0.18
Appearance dimensions mm 860*720*1950
Packaging dimensions mm 900*1000*2090
Net weight kgs 210
Number of processing setting groups 1
Number of processing setting segments 10
Processing method Upward processing, downward processing
Shaking method None
Maximum number of holes for continuous processing 1
